Part Number
|
SPC-821-633AG |
SPC-821-633AP |
Environment
|
|
|
| Humidity |
10 ~ 95% RH @ 40°C, non-condensing (Note: Tested for 48hrs)
|
10 ~ 95% RH @ 40°C, non-condensing (Note: Tested for 48hrs)
|
|
Storage Temperature
|
-20 ~ 60° C (-4 ~ 140° F)
|
-20 ~ 60° C (-4 ~ 140° F)
|
|
Operating Temperature
|
0 ~ 55°C (32 ~ 131°F)
|
0 ~ 55°C (32 ~ 131°F)
|
|
Vibration Protection
|
With SSD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)
|
With SSD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration)
|
General
|
|
|
| Cooling System |
Fanless design
|
Fanless design |
| Dimensions (W x H x D) |
546.69mm x 420.34mm x 67mm (w/o Flange for arm mount), 546.69mm x 420.34mm x 160mm (w/ Flange for arm mount) |
546.69mm x 420.34mm x 67mm (w/o Flange for arm mount), 546.69mm x 420.34mm x 160mm (w/ Flange for arm mount) |
| Mounting |
Pole Mount (Pedestal & Pendant, support Rittal's CP40
& Bernstein's CS-480 B.Flex joint dimension), VESA (Optional) |
Pole Mount (Pedestal & Pendant, support Rittal's CP40
& Bernstein's CS-480 B.Flex joint dimension), VESA (Optional) |
| Power Consumption |
60W(Typical)
|
60W(Typical)
|
| Power Input |
Phoenix Jack: 24 VDC input
|
Phoenix Jack: 24 VDC input
|
| Certifications |
CE,FCC,UL,CB,CCC
|
CE,FCC,UL,CB,CCC |
| Enclosure |
Front panel: Die-casting aluminium,Rear cover: Die-casting aluminium
|
Front panel: Die-casting aluminium,Rear cover: Die-casting aluminium
|
| OS Support |
Microsoft Windows10 IoT 2016 Enterprise LTSB (64 bit)
|
Microsoft Windows10 IoT 2016 Enterprise LTSB (64 bit)
|
| Weight |
10 kg (22.04 lb)
|
10 kg (22.04 lb)
|
| LCD Display |
|
|
|
Display Size
|
21.5"
|
21.5"
|
| Display Type |
Full HD TFT LED LCD
|
Full HD TFT LED LCD
|
| Max. Colors |
16.7M
|
16.7M
|
|
Max. Resolution
|
1920 x 1080
|
1920 x 1080
|
|
Viewing Angle (H/V°)
|
178/178
|
178/178 |
|
Luminance (cd/m2)
|
250
|
250 |
|
Touchscreen
|
4096 x 4096 dot
|
4096 x 4096 dot |
| Light Transmission |
≥88%
|
≥88%
|
| Type |
Projected capacitive
|
Projected capacitive |
Hardware
|
|
|
|
I/O
|
USB 2.0 x 1 (Front), USB 3.0 x 2 |
USB 2.0 x 1 (Front), USB 3.0 x 2 |
|
Memory
|
8GB SO-DIMM DDR3L SDRAM, Up to 16GB RAM
|
8GB SO-DIMM DDR3L SDRAM, Up to 16GB RAM
|
|
CPU
|
6th Gen Intel® Core™ i3-6100U 2.30 GHz
|
6th Gen Intel® Core™ i3-6100U 2.30 GHz
|
| Expansion Slots |
Full-sized Mini PCI-E x 1 (optional)
|
Full-sized Mini PCI-E x 1 (optional)
|
|
LAN
|
2x 10/100/1000Base-T (1 x Intel® 210 , 1 x Intel® 219)
|
2x 10/100/1000Base-T (1 x Intel® 210 , 1 x Intel® 219)
|
