| Условия окружающей среды |
Humidity |
10 ~ 95% RH @ 40°C, non-condensing |
| Ingress Protection |
Front panel: IP65 |
| Operating Temperature |
0 ~ 50°C (32 ~ 131°F) |
| Storage Temperature |
-20 ~ 60°C (-4 ~ 140°F) |
| Vibration Protection |
With HDD: 1 Grms (5 ~ 500 Hz) (Operating, random vibration) |
| Параметры экрана |
Backlight Life |
50,000 hrs |
| Contrast Ratio |
700:1 |
| Display Size |
10.4" |
| Display Type |
SVGA TFT LED LCD |
| Luminance (cd/m2) |
600 |
| Max. Colors |
16.2M |
| Max. Resolution |
1024 x 768 |
| Viewing Angle (H/V°) |
160/140 |
| Сенсорный экран |
Lifespan |
36 million touches at single point |
| Light Transmission |
Above 75% |
| Resolution |
Linearity |
| Type |
5-wire, analog resistive |
| Порты ввода-вывода |
I/O |
RS-232 x 1, RS-232/422/485 x 1, USB 3.0 x 1, USB 2.0 x 1 |
| Общие характеристики |
Потребляемая мощность |
16W Typical |
| Power Input |
12-24 VDC |
| Watchdog Timer |
1 ~ 255 sec (system) |
| Вес (Нетто) |
1.9 kg |
| Аппаратное обеспечение |
Chipset |
|
| CPU |
Intel Celeron N2930 QC 1.83ГГц |
| Expansion Slots |
Full-size Mini PCI-E |
| LAN |
10/100/1000 Base-T x 2 (one port supports iAMT) |
| Memory |
1 x SO-DIMM, DDR3L 1333, Max 8 GB |
| Storage |
mSATA slot x 1 (via Mini PCIe) + опицонально 2.5" SATA SSD slot |
| Прочие характеристики |
OS Support |
Microsoft® Windows WES7 32bit/64bit /WES8 64bit /Windows 7 32bit/64bit / Windows 8 64bit Linux Kernel 3.x |
| Mounting |
Desktop, Wall or Panel Mount |
| BIOS |
AMI UEFI |
| Enclosure |
Front bezel: Die-cast Aluminum alloy, Back housing: PC/ABS Resin |
| Certifications |
BSMI, CCC, CE, FCC Class A, UL |
| Охлаждение |
Пассивное, без вентиляторов |
| Габариты (W x H x D) |
272 x 217 x 46 mm (10.7" x 8.5" x 1.8") |
