Power Supply
|
|
|
Power Consumption
|
18W (Burn-in test 7.0 in Windows 7 32 bit)
|
| Input Voltage |
12-24 VDC
|
|
LCD Display
|
|
|
Viewing Angle (H/V°)
|
80 (left), 80 (right), 70 (up), 70 (down)
|
| Luminance (cd/m2) |
500
|
| Contrast Ratio |
700:01:00
|
| Display Type |
15" TFT LCD (LED Backlight)
|
| Backlight Life |
30,000 hrs (Min.)
|
|
Environment
|
|
|
Relative Humidity
|
10 ~ 95% @ 40°C non-condensing
|
| EMC |
CE, FCC Class B, BSMI
|
| Safety |
CB, CCC, BSMI, UL
|
| Operating Temperature |
0 ~ 50°C (32 ~ 122°F) with SSD, 0 ~ 40°C (32 ~ 104°F) with HDD
|
| Storage Temperature |
-40 ~ 60°C (-40~140°F)
|
| Front Panel Protection |
IP65 Compliant
|
| Vibration |
Operating Random Vibration Test 5~500Hz, 1Grms @with HDD; 2Grms @with SSD, follow IEC 60068-2-64
|
| Shock |
Operating 10 G peak acceleration (11 ms duration), follows IEC 60068-2-27
|
|
Processor System
|
|
|
Memory
|
1 x SO-DIMM, DDR3L 1333, Max 8 GB
|
| Frequency |
1.83 GHz
|
| I/O Ports |
2 x Serial ports: 1 x RS-232, 1 x RS-232/422/485(Adjustable through BIOS), 2 x USB 2.0; 1 x USB 3.0
|
| Network (LAN) |
2 x 10/100/1000 Mbps Ethernet (Intel I211)
|
| Storage 1 |
1 x 2.5" SATA bay, 1 x mSATA bay
|
| Watchdog Timer |
255 timer levels; setup by software
|
| CPU |
Intel® Celeron® N2930, Quad core
|
| Expansion Slots |
1 x Full size Mini PCIe slot
|
|
Touchscreen
|
|
|
Light Transmission
|
80±5% at 550 nm wavelength
|
| Controller |
RS-232 interface
|
| Durability (Touches) |
Greater than 35 million touches in one location without failure
|
| Touch Type |
Elo Resistive 5 wires
|
|
OS Support
|
|
|
OS Support
|
Microsoft® Windows 7 32bit&64bit/Windows 8.1 32bit&64bit/Windows 10 32bit&64bit/WES7/WEC 7/Linux/Android 4.4
|
|
Physical Characteristics
|
|
|
Dimensions
|
317 x 246 x 49 mm(12.5" x 9.7" x 1.9")
|
| Weight |
2.1 Kg (4.63 lb)
|
