Part Number
|
ARK-2232L-S6A2 |
Processor
|
|
|
CPU
|
Intel Atom E3940 Quad Core Soc
|
|
Core Number
|
4 |
|
Frequency
|
1.6 GHz, turbo burst 1.8GHz
|
|
L2 Cache
|
2 MB
|
|
BIOS
|
AMI EFI 64 Mbit
|
Memory
|
|
|
Technology
|
DDR3L 1866 MHz
|
|
Max. Capacity
|
8 GB
|
|
Socket
|
1 x 204-pin SO-DIMM
|
Graphics
|
|
|
Chipset
|
Intel® HD Graphics 500
|
|
Graphic Engine
|
4K Codec Decode& Encode for H.264, MPEG2, MVC, VC-1, WMV9, H.265 / HEVC, VP8, JPEG / MJPEG
|
|
VGA
|
Up to 1920 x 1200 at 60 Hz
|
|
HDMI
|
HDMI 1.4b for HD video playback, 3840 x 2160 at 30Hz
|
|
Dual Display
|
Yes, VGA + HDMI
|
Ethernet
|
|
|
LAN1
|
10/100/1000 Mbps Intel I210-IT GbE, support Wake on LAN
|
|
LAN2
|
10/100/1000 Mbps Intel I210-IT GbE, support Wake on LAN
|
Audio
|
|
|
Interface
|
Realtek ALC888S, High Definition Audio, Line-out, Mic-in
|
I/O
|
|
|
Serial port
|
2 x RS-232 ports, 2 x RS-232/422/485 port with auto flow control
|
|
Digital I/O
|
8bit programmable general purpose input/output
|
|
USB
|
2 x USB 3.0, 4 x USB 2.0
|
Others
|
|
|
Watchdog timer
|
255 levels timer interval, setup by software
|
Expansion
|
|
|
Mini PCIe
|
1 x full size Mini PCIe with SIM holder
|
|
M.2
|
1 x M.2 2230 E Key
|
Storage
|
|
|
HDD
|
Supports one SATA 2.5" HDD Bay (Compatible with 12.5mm height HDD) (Max. Data Transfer Rate 300 MB/s)
|
|
mSATA
|
1 x full size mSATA socket (share with miniPCIe)
|
Software Support
|
|
|
Linux
|
Support by project
|
|
Microsoft Windows
|
Windows 10
|
Power
|
|
|
Power Type
|
AT/ATX
|
|
Input Voltage
|
12 VDC (9 ~ 36 VDC as option)
|
|
Power Adaptor
|
AC to DC, DC12V/5A, 60 W (Optional)
|
|
Consumption
|
Typical 7.98 W, Max. 19.76 W
|
Mechanical
|
|
|
Construction
|
Aluminum housing
|
|
Mounting
|
Din-Rail mounting, Desk/wall-mounting, VESA mounting
|
|
Dimensions
|
260 x 44 x 140.2 mm (10.24" x 1.73" x 5.52")
|
|
Weight
|
Net Weight: 1.9kg (4.19 lbs); Gross Weight: 2.9kg (6.39 lbs)
|
Environment
|
|
|
Operational Temperature
|
With extended temperature peripherals: -20 ~ 60 °C (-4 ~ 140 °F) with 0.7m/s air flow, With 2.5-inch hard disk 0 ~ 40 °C (32 ~ 104 °F) with 0.7m/s air flow
|
|
Storage Temperature
|
-40 ~ 85° C (-40 ~ 185° F)
|
|
Relative Humidity
|
95% @ 40° C (non-condensing)
|
|
Vibration during Operation
|
With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
|
|
Shock During Operation
|
With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
|
Certification
|
|
|
EMC
|
CE/FCC Class B, CCC, BSMI |
|
Safety Certifications
|
UL, CCC, BSMI, CB
|
