15.6" Ubiquitous PC for retail Advantech UTC-115K

15.6" Ubiquitous Touch Computer with 12th Gen Intel® Core™ N97 / i3-N305 Processor Advantech UTC-115K

Price and avalability

Partnumber	Description	Price VAT incl	Avalability
UTC-115KP-WWW1F	15.6", pcap, N97, 8G, 128G, Win11, WF	92 831,0
UTC-115KP-NWW1F	15.6", P-Cap, N97, 8G, 128G, WF, w/o OS	86 449,4
UTC-115KP-NWW1F	15.6", P-Cap, N97, 8G, 128G, WF, w/o OS	86 449,4

• Slimmer and Lighter design
• Low power and fanless system design
• Built-in Intel® N97/i3-N305
• 15.6" monitor with 16:9 widescreen display
• IP65-rated front panel for water and dust resistance
• Clean back cover design with 3 Way IO cable routing
• Supports both landscape and portrait screen orientations
• VESA 100 mm standard mounting holes for varied mounting demands
• Support DeviceOn/iService software for remote device management

Additional information

Process system
CPU	Intel Processor N97 Intel Core i3-N305
Base Frequency	N97: 2.0 GHz (4 cores) i3: 1.8 GHz (8 cores
Memory	1 x 262pin SO-DIMM DDR5 4800MHz up to 16GB
Storage	1 x 2.5 internal SATA storage*, M.2 2242/2280 SSD
Network	2 x Gigabit Ethernet ports (Supports Wake on LAN)
I/O Ports	2 x RS-232 COM (COM2 RS-232/422/485) 2 x USB 3.2 Gen1 Type-A 2 x USB 2.0 1 x USB 3.2 Gen 1 Type-C 1 x DC-in USB Type-C 2 x Gigabit Ethernet ports 1 x HDMI 1.4 1 x Audio Phone Jack
Stereo Speaker	2 x 2W
Bus expansion	1 x M.2 key2230, 1 x M.2 key2280
Mounting	VESA 100 x 100 mm (Screw Size, M4, 7mm)
Dimension (WxHxD)	398.8 x 248.2 x 29.5 mm
Weight	2.4kg
OS Support	Win 10/11 IoT Enterprise 64bit Linux, Android 14
Environment Specification
Operating temperature	0 ~ 40 °C (32 ~ 104 °F)
Relative Humidity	10 ~ 95% @ 40 °C non-condensing
Vibration	0.5G
Shock	Shock 10G peak acceleration(11 msec. duration)
Certification	CE, FCC, CB, UL, CCC, BSMI
Front Panel Protection	IP 65 Compliant
Power Supply
DC Input Rating	20V/4.5A (90W)
Power consumption	45W
LCD Display
Size/Type	15.6" FHD
Max.Resolution	1920 x 1080
Max. Color	262K
Pixel Pitch (um)	179(H) x 179(V)
Brightness (cd/m2 )	400
View Angle	170°/170°
Touch Screen Option
Type	Projected Capacitive.
Light Transmission	> 85%
Controller	USB Interface
TPM	TPM 2.0
