Processor System
|
|
|
CPU |
Intel® Celeron® N3350 (UTC-207G) |
Intel® Pentium® N4200 (UTC-207G) |
Base Frequency |
1.10 GHz (Dual-Core) |
1.10 GHz (Quad-Core) |
Cache |
L2 Cache 1MB |
L2 Cache 2MB |
Memory |
1 x SO-DIMM DDR3L 1866 MHz up to 8 GB |
1 x SO-DIMM DDR3L 1866 MHz up to 8 GB |
Storage |
1 x M.2 2242 SSD |
1 x M.2 2242 SSD |
Network (LAN) |
2 x Gigabit Ethernet ports (Supports Wake on LAN) |
2 x Gigabit Ethernet ports (Supports Wake on LAN) |
I/O ports |
- 2 x RS-232 COM (COM2 RS-232/422/485)
- 2 x USB3.0 / 2 x USB3.0 (optional)
- 2 x Gigabit Ethernet ports (1 with PoE)
|
- 2 x RS-232 COM (COM2 RS-232/422/485)
- 2 x USB3.0 / 2 x USB3.0 (optional)
- 2 x Gigabit Ethernet ports (1 with PoE)
|
Stereo Speaker (Optional) |
1 x 2W |
1 x 2W |
Bus expansion |
1 x M.2 key2230, 1 x M.2 key2242 |
1 x M.2 key2230, 1 x M.2 key2242 |
Dimensions (W x H x D) |
180 x 116.5 x 32.5 mm |
180 x 116.5 x 32.5 mm |
Weight |
0.95kg (2.09lbs) |
0.95kg (2.09lbs) |
OS Support (Optional)
|
- Win 10 IoT Enterprise 64bit
- Android 6.0/8.1/10
- Linux
|
- Win 10 IoT Enterprise 64bit
- Android 6.0/8.1/10
- Linux
|
Environmental Specifications |
|
|
Operating Temperature |
0 ~ 40 °C (32 ~ 104 °F)* |
0 ~ 40 °C (32 ~ 104 °F)* |
Relative Humidity |
10 ~ 95% @ 40 °C non-condensing |
10 ~ 95% @ 40 °C non-condensing |
Vibration |
0.5G |
0.5G |
Shock |
10G peak acceleration (11 msec. duration) |
10G peak acceleration (11 msec. duration) |
Certification |
CE, FCC |
CE, FCC |
Power Supply
|
|
|
DC Input Rating |
12 V/3 A ~ 24 V/1.5 A, 36W ITE Adapter |
12 V/3 A ~ 24 V/1.5 A, 36W ITE Adapter |
PoE |
Optional IEEE 802.3at/30W |
Optional IEEE 802.3at/30W |
Power consumption |
|
|
LCD Display
|
|
|
Size/Type |
7" TFT LCD with LED backlight |
7" TFT LCD with LED backlight |
Max.Resolution |
800 x 480 |
800 x 480 |
Max. Color |
262K |
262K |
Pixel Pitch (um) |
192.6 x 179 |
192.6 x 179 |
Brightness (cd/m2 ) |
450 |
450 |
View Angle |
140°/ 160° |
140°/ 160° |
Touch Screen Option (PE/GE)
|
|
|
Angle 140°/ 160° Touch Screen Option (PE/GE) |
|
|
Type |
Projected Capacitive. Glass Panel |
Projected Capacitive. Glass Panel |
Light Transmission |
80% ± 5% / 90% |
80% ± 5% / 90% |
Controller |
USB Interface |
USB Interface |
