17" powerful panel PC Winmate R17IK3S-65A1

17" powerful panel computer Winmate R17IK3S-65A1 fanless, full IP65, Core i5th

Industrial Computer >> Allround protected PC

 Price and avalability

Manufacturer: Winmate Communication, Inc.

Fully protected The 17-inch Winmate stainless steel panel computer has an IP65 protection level and is designed to automate production in the food, processing and pharmaceutical industries.

  • 17" TFT XGA LCD
  • Intel 7th ® Gen. Core TM i5-7200U Kaby Lake 2.5GHz (turbo to 3.1GHz
  • Fanless Design
  • Full IP65 ( dust/water resistant)
  • Stainless Housing with Anti-Corrosion Treatment
  • Optical Bonding with Anti-moisture Treatment (Optional)
  • 5 Wire Resistive Touch ( or Anti-Reflection Protection Glass, optional)

Price and avalability

Partnumber Description Price VAT incl Avalability
R17IK3S-65A1/PAT Пaнельный компьютер 17" с защитой IP65 и нержавеющим корпусом Winmate. PCAP сенсорный экран. Процессор Intel Intel Core i5-7200U 2.5GHz, 8GB DDR4, 256GB SSD, без ОС, with one extra LAN (2xLAN)  82 863,0
R17IK3S-65A1/128/GS Пaнельний комп'ютер Winmate 17" із повним захистом IP65 та нержавіючим корпусом. Антиблікове захистне скло. Процесор Intel Intel Core i5-7200U 2.5GHz, 4GB DDR4, 128GB m.2 SSD, без ОС.  71 903,7
R17IK3S-65A1/128/GS/Win10 Пaнельний комп'ютер Winmate 17" із повним захистом IP65 та нержавіючим корпусом. Антиблікове захистне скло. Процесор Intel Intel Core i5-7200U 2.5GHz, 4GB DDR4, 128GB m.2 SSD, Windows 10 IoT  76 715,1

Additional information

LCD Panel Specification

Size 17"
Active Display Area 337.92 (H) x 270.34 (V)
Pixel Pitch 0.264 (H) x 0.264 (V)
Resolution 1280 x 1024
Contrast Ratio 1000:1 (typ.)
Display Color 16.7M (6bits+FRC)
Brightness 350 (typ.)
Viewing Angle -85~85 (H); -80~80 (V)
Recommend Resolution 1280x1024@60HZ,75HZ
Touch Sensor Type 5 Wires Resistive(Optional)

System Specification

FormFactor 3.5"
Processor Intel 5th ® Gen. Core TM i5-7200U Kaby Lake 2.5GHz (turbo to 3.1GHz)
Memory DDR4-2133 SO-DIMM (Max 16GB)
BIOS Insyde BIOS
Ethernet Intel® Gigabit-LAN Controller I211AT + PHY I219LM
Serial 1 x RS232
USB 2 x USB 2.0
Storage 64GB M.2 B Key SATA III (Options up to 256GB)
OS Windows 10 IoT Enterprise

Mechanical and Environment

Operating Temperature 0°C to 45°C
Operating Humidity 30% to 90% (non-condensing)

Power

Power Input 12V DC IN (Lockable Power Jack)
Power Consumption 56W (typ.)- max backlight & high CPU load

Order Options

RAM DDR4-2133 SO-DIMM (Max 16GB)
Storage 64GB M.2 B Key SATA III (Options up to 256GB)
Mechanical Stainless Chassis
Touch 5 Wire Resistive Touch/ Anti-Reflection Protection Glass
OS Windows 10 IoT Enterprise
