IP65

8" Industrial-Grade Tablet Advantech with Qualcomm® Snapdragon™ 660 Processor, Android 10 with GMS AIM-75S

Price and avalability

Partnumber Description Price VAT incl Avalability
AIM-75S-221S10 AIM75S_WIFI, EU, EEA GMS  73 655,3
AIM-75S-621S10 Промисловий планшет Advantech AIM75S 8" IPS LCD/LTE/Wi-Fi/EU/EEA/Qualcomm® Snapdragon™ 660 octa-core 2.2 GHz/4GB/eMMC64GB/Android 10 глобальна версія (крім Туреччини та росії)  94 479,6
AIM-75S-211S10 Промисловий планшет Advantech AIM75S_WIFI, Global, ROW GMS  73 655,3
AIM-75S-200S10 AIM75S_WIFI, none-GMS  73 655,3
AIM-75S-611S10 Промисловий планшет Advantech AIM75S_LTE, Global, ROW GMS  88 121,1

AIM-75S is an industrial-grade tablet equipped with IP65-rated protection from water and dust ingress and a swappable battery that supports up to 12 hours of operation, making it suitable for diverse indoor and outdoor vertical applications. In addition to WLAN/LTE capabilities that enable mobile computing, AIM-75S can be integrated with optional peripherals such as a 1D/2D barcode scanner, LAN+COM, UHF RFID, and MSR modules to support a wide range of operations in the manufacturing, warehouse, retail, and field service industries. Moreover, AIM-75S is equipped with Advantech’s DeviceOn/iService software, which is a next-generation unified device management solution based on the WISE-DeviceOn platform. With support for batch operations and multi-device control, DeviceOn/iService enables easy device configuration and deployment for convenient remote device management.

  • Equipped with DeviceOn/iService software for remote device management
  • Qualcomm® Snapdragon™ 660 with Android 10 operating system
  • Certified for Google Mobile Services for downloading apps and APIs
  • 8" LCD with 400-nit brightness, 1920 x 1200 resolution
  • Corning® Gorilla® Glass 3 touchscreen supports gloved and stylus operation
  • IP65-rated protection from water and dust and 4-ft drop tolerance
  • LTE, WLAN, Bluetooth, NFC, and GIS capabilities
  • Optional peripherals include 1D/2D barcode scanner, LAN+COM, UHF RFID, and MSR modules
  • Multi-bay charging and docking stations ensure easy installation in diverse environments

Additional information

System

Processor Qualcomm® Snapdragon™ 660 octa-core 2.2 GHz
Memory 4 GB LPDDR4x
Operating System Android 10 with GMS

Storage

eMMC 64 GB
Micro SD Supports up to 2 TB

Display

Type 8" IPS LCD
Resolution WUXGA 1920 x 1200
Brightness 400 cd/m²
Touch Type 10-point multi-touch PCAP touch control
Glass Type Corning® Gorilla® Glass 3

Communication

WLAN IEEE 802.11 a/b/g/n/ac/k/v/r
Bluetooth Bluetooth® v5.0
WWAN (Optional) Global Cat. 4/6 4G LTE (data only)
NFC 13.56 MHz, compatible with ISO15693, ISO14443A, ISO 14443B, FeliCa

Connectivity

Standard I/O 1 x USB Type-C 3.0 , 1 x combo audio jack, 1 x SIM card reader, 1 x micro SD card reader
Extended I/O 1 x AIM extension 14-pin pogo connector: 1 x USB 2.0, 1 x 2-wire UART, 5V/1A power
Docking 1 x AIM docking 16-pin pogo connector: 1 x USB 2.0, 9V power
Speaker 1 x Internal speakers (1.5W)

GPS

GPS Glonass/Beidou/Galileo/QZSS/SBAS

Audio

Audio Jack 1 x Audio combo jack (combines stereo audio output and mono microphone input)

Camera

Front 5 megapixel fixed-focus camera
Rear 8 megapixel auto-focus camera with LED flash
Sensors Ambient light sensor, P-sensor, e-compass, g-sensor, gyroscope
Control Buttons 1 x Power button, 2 x volume keys (up/down), 1 x programmable function key
System Indicators Full: green (100%); charging: blue; low charge: red ( 10%)

Power System

Input Voltage
  • USB Type-C: 5V/3A, 9V/3A
  • Dock pogo: 9V/2A
Battery
  • Swappable battery: 4900 mAh (minimum) 18.6 WHr
  • Operating time: up to 12 hrs*
  • Charging time: < 3 hrs*

Environmental

Operating Temperature -10 ~ 50 °C
Storage Temperature -20 ~ 60 °C
IP Rating IP65
Shock SAE J1455
Vibration SAE J1455
Humidity
  • Operating: 10 ~ 90% @ 40 °C/104 °F non-condensing
  • Storage: -10 ~ 95% non-condensing
Drop Tested Up to 120 cm (4 ft) onto plywood

Physical Characteristics

Dimensions (W x D x H) 240 x 142 x 14.5 mm/9.44 x 5.59 x 0.57 in
Weight 600 g/1.32 lb
Color Dark gray
Certifications FCC, CE, TELEC, NCC, RCM, IC, VCCI, PTCRB, SRRC, CB, UL, CCC, BSMI
