Rackmount Chassis HPC-7282

2U Rackmount Chassis Advantech HPC-7282 for MircoATX/ATX Server Board with 8 Hot-swap Drive Bays, 7 Low Profile Expansion Slots

System Components >> Rackmount computer chassis

 Price and avalability

Manufacturer: Advantech Co., Ltd.

2U Rackmount Chassis for MircoATX/ATX Server Board with 8 Hot-swap Drive Bays, 7 Low Profile Expansion Slots

  • 2U rackmount chassis supports MicroATX/ATX motherboard
  • Eight hot swap SAS/SATA drive bays
  • Swappable fan module design facilitates maintenance
  • Supports 7 x Low-Profile/Half-Length I/O Expansion Slots

Price and avalability

Partnumber Description Price VAT incl Avalability
HPC-7282-00A1E Серверный корпус для материнской платы HPC-7282 2U 8 bays server chassis (w/o PSU)  25 140,6

Additional information

Part Number HPC-7282-00A1E

Drive Bay


Hot Swap External 8 (3.5") Lockable
Internal 3.5" 2
Slim Optical Drive External 1

Environment


Non-Operating Humidity 10 ~ 95% @ 40° C, non-condensing
Non-Operating Vibration (5 ~ 500 Hz) 0.5 Grms
Non-Operational Temperature -40 ~ 70° C (-40 ~ 158° F)
Operating Humidity 10 ~ 85% @ 40° C, non-condensing
Vibration (5 ~ 500 Hz) 0.25 Grms
Operating Temperature 0 ~ 40° C (32 ~ 104° F)

Front I/O Interface


COM Port 1
USB2.0 10 D-sub openings supporting up to 10 COMs with optinal COM cables

Miscellaneous


LED Indicators Power, HDD, LAN1, LAN2, System Information

Physical Characteristics


Dimensions (W x H x D) 437 x 88.9 x 533.4 mm (17.2" x 3.5" x 21")

Cooling


System Fan 3 x 80 mm Fan Module with swappable bracket
