Part Number
|
ARK-11-S1A2 |
Processor
|
|
|
CPU
|
Intel Celeron N3350 Dual Core SoC
|
|
Frequency
|
1.1 GHz, turbo burst 2.4 GHz
|
|
Core Number
|
2 |
|
BIOS
|
AMI EFI 64 Mbit
|
Memory
|
|
|
Technology
|
DDR3L 1866 MHz
|
|
Max. Capacity
|
8GB, 1 x 4GB memory (-40 ~ 85 °C) built-in
|
|
Socket
|
2 x 204-pin SO-DIMM
|
Graphics
|
|
|
Chipset
|
Intel HD Graphics 500, CPU integrated
|
|
Graphic Engine
|
Gen9 Low Power; 18 Execution Units Media Codec Supported: H.264, MPEG2, MVC, VC-1, WMV9, H.265 / HEVC, VP8, JPEG / MJPEG, 3D HW Acceleration: OpenGL 4.4, DirectX* 12, OpenCL* 2.0
|
|
HDMI
|
HDMI1 : 3840 x 2160 @ 30Hz; HDMI2 : 3840 x 2160 @ 30Hz
|
|
Dual Display
|
HDMI1 + HDMI2
|
Ethernet
|
|
|
LAN1
|
10/100/1000 Mbps Intel i210 GbE, support Wake On Lan
|
|
LAN2
|
10/100/1000 Mbps Intel I210 GbE, support Wake on LAN
|
Audio
|
|
|
Interface
|
Realtek ALC888S, High Definition Audio, Line-out, Mic-in
|
I/O
|
|
|
Serial port
|
2 x RS-232/422/485 with auto flow control, COM2 with 5V/12V power supply
|
|
USB
|
4 x USB 3.0
|
|
GPIO
|
8-bit Programmable DIO (Optional)
|
Expansion
|
|
|
Mini PCIe
|
1 x Full-size mPCIe with SIM holder
|
|
M.2
|
1 x M.2 2230 E key for WIFI module
|
Storage
|
|
|
2.5" HDD/SSD
|
1 x 2.5" 64G MLC SSD (-40~85°C) built-in
|
|
mSATA
|
1 x Full-size mSATA (*share with mPCIe slot)
|
Others
|
|
|
Watchdog timer
|
255 levels timer interval, setup by software
|
Software Support
|
|
|
Microsoft Windows
|
Windows 10 IoT Enterprise built-in
|
|
Linux
|
Support by project
|
| Power |
|
|
Power Type
|
AT/ATX
|
|
Input Voltage
|
12 ~ 28 VDC
|
|
Power Adaptor
|
AC to DC, 24V/2.5A 60W adaptor built-in
|
Power Consumption
|
|
|
Typical
|
6.4W
|
|
Max.
|
18.1W
|
Mechanical
|
|
|
Construction
|
Aluminum housing
|
|
Mounting
|
DIN-rail/Wall Mount
|
|
Dimensions
|
53.5 x 158 x 114 mm (2.11" x 6.22" x 4.49")
|
|
Weight
|
1.2 kg (2.65lb)
|
Environment
|
|
|
Operational Temperature
|
With extended temp. peripherals: -30 ~ 70 °C (-22 ~ 158 °F) with 0.7 m/s air flow, With 2.5 inch hard disk: 0 ~ 40 °C (32 ~ 104 °F) with 0.7 m/s air flow
|
|
Storage Temperature
|
-40 ~ 85° C (-40 ~ 185° F)
|
|
Relative Humidity
|
95% @ 40° C (non-condensing)
|
|
Vibration during Operation
|
With SSD: 3 Grms, IEC 60068-2-64, random, 5 ~ 500 Hz, 1 hr/axis
|
|
Shock During Operation
|
With SSD: 30 G, IEC 60068-2-27, half sine, 11 ms duration
|
Certification
|
|
|
EMC
|
CE/FCC Class B, CCC, BSMI
|
|
Safety Certifications
|
UL, CB, CCC, BSMI
|
