Процесор і чіпсет
|
|
Processor
|
Intel® Xeon® E3-1505M v5/ Core™ i7-6820EQ/ i5-6440EQ Processor (Skylake-H)
|
|
Chipset
|
Intel® CM236
|
|
BIOS
|
AMI
|
|
SIO
|
IT8786E
|
|
Memory
|
2 DDR4 2133MHz SO-DIMM, up to 32GB
|
|
Порти вводу-виводу та інтерфейси
|
|
Serial
|
4 COM RS-232/ 422/ 485
|
|
USB
|
- 4 USB 3.0 (External)
- 1 USB 2.0 (Internal)
|
|
Isolated DIO
|
16 Isolated DIO : 8 DI, 8 DO
|
|
GPIO
|
16 GPIO
|
|
LED
|
Power, HDD, Wireless, PoE
|
|
SIM Card
|
4 SIM Card Socket (3 External, 1 Internal)
|
|
Слоти розширення
|
|
Mini PCIe
|
4 Mini PCIe Socket :
- 1 Mini PCIe for PCIe/ USB/ Internal SIM Card/ Optional mSATA
- 3 Mini PCIe for PCIe/ USB/ External SIM Card
|
|
SUMIT A, B
|
2 SUMIT Slot (Optional)
|
|
Графічне ядро
|
|
Graphics Processor
|
- Intel® HD Graphics P530/ 530
|
|
Display Memory
|
Shared Memory, up to 1.7GB
|
|
Interface
|
- DVI-D : Up to 1920 x 1200 @ 60Hz
- DisplayPort 1 : Up to 4096 x 2304 @ 60Hz
- DisplayPort 2 : Up to 4096 x 2304 @ 60Hz
|
|
Накопичувачі
|
|
SATA
|
6 SATA III (6Gbps) support S/W RAID 0, 1, 5, 10
|
|
mSATA
|
1 SATA III (Mini PCIe Type, 6Gbps)
|
|
Storage Device
|
- 1 CFast Socket, Push-in/ Push-out Ejector
- 4 Front-access 2.5" SSD/ HDD Tray
|
|
Звукова підсистема
|
|
Audio Codec
|
Realtek ALC892, 5.1 Channel HD Audio
|
|
Audio Interface
|
1 Mic-in, 1 Line-out
|
|
Ethernet
|
|
LAN 1
|
Intel® I219 Gigabit LAN supports iAMT 11.0
|
|
LAN 2
|
Intel® I210 Gigabit LAN
|
|
PoE
|
|
LAN 3
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 4
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 5
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 6
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 7
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 8
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 9
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 10
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 11
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 12
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 13
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 14
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 15
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 16
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 17
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
LAN 18
|
Gigabit IEEE 802.3at (25.5W/48V) PoE+ by Intel® I350
|
|
Живлення
|
|
Power Input
|
6V to 78V, DC-in
|
|
Power Interface
|
- 3-pin Terminal Block : V+, V-, Frame Ground
|
|
Ignition Control
|
16 Mode (Internal)
|
|
Remote Switch
|
5-pin Terminal Block : On, Off, IGN, LED+, LED-
|
|
Surge Protection
|
Up to 200V/1ms Transient Power
|
|
UPS
|
Supported (Optional)
|
|
Інші можливості
|
|
TPM
|
Optional Infineon SLB9665 supports TPM 2.0, LPC Interface
|
|
Watchdog Timer
|
Reset : 1 to 255 sec./min. per step
|
|
Smart Management
|
Wake on LAN, PXE supported
|
|
HW Monitor
|
Monitoring temperature, voltages. Auto throttling control when CPU overheats.
|
|
GPS
|
Onboard GPS Module supports Accelerometer, Gyroscope and Odometer (Optional)
|
|
Підтримка ПЗ
|
|
OS
|
Windows 10, Windows 8.1, Windows 7, Linux
|
|
Фізичні характеристики
|
|
Dimension (W x L x H)
|
260mm x 215mm x 79mm (10.2” x 8.5” x 3.1”)
|
|
Weight
|
4.2 kg (9.26 lb)
|
|
Mounting
|
- Wallmount by mounting bracket
- 2U Rackmount (Optional)
|
|
Умови експлуатації
|
|
Operating Temperature
|
-25°C to 70°C (-13°F to 157°F)
|
|
Storage Temperature
|
-40°C to 85°C (-40°F to 185°F)
|
|
Humidity
|
5% to 95% Humidity, non-condensing
|
|
Relative Humidity
|
95% at 70°C
|
|
Shock
|
- IEC 60068-2-27
- SSD : 50G @ wallmount, Half-sine, 11ms
|
|
Vibration
|
- IEC 60068-2-64
- SSD : 5Grms, 5Hz to 500Hz, 3 Axis
|
|
EMC
|
CE, FCC, EN 50155, EN 50121-3-2
|
