Processor System
|
|
|
|
| CPU |
Intel® Celeron® J1900 (UTC-542D) |
Intel® Core™ i7-6600U (Available)* Intel® Core™ i5-6300U (UTC-542F) Intel® Core™ i3-6100U (Available)* |
Intel® Pentium® N4200 (UTC-542G) Intel® Atom® E3950 (Available)* |
| Base Frequency |
2 GHz (Quad-Core) |
2.4 GHz (Dual-Core) |
1.1 GHz (N4200/Quad-Core) 1.6 GHz (E3950/Quad-Core) |
| Cache |
2 MB |
3 MB |
L2 Cache 2MB |
| Memory |
1 x 204 pin SO-DIMM DDR3L 1333 MHz up to 8 GB |
2 x 204 pin SO-DIMM DDR3L 1600Mhz up to 16G |
1 x 204 pin SO-DIMM DDR3L 1867 MHz up to 8GB |
| HDD/SSD |
Dual hot-swappable HDD/SSD slots with RAID 0,1 support |
Dual hot-swappable HDD/SSD slots with RAID 0,1 support |
Dual hot-swappable HDD/SSD slots with RAID 0,1 support |
| Network (LAN) |
2 x Gigabit Ethernet ports |
2 x Gigabit Ethernet ports |
2 x Gigabit Ethernet ports |
| I/O Ports |
2 x RS-232 COM (RS-422/485)* 4 x USB 2.0 / 1 x USB 3.0 2 x Gigabit Ethernet (RJ-45) 1 x VGA 1 x HDMI |
2 x RS-232 COM (RS-422/485)* 3 x USB 2.0 / 2 x USB 3.0 2 x Gigabit Ethernet (RJ-45) 1 x VGA 1 x HDMI |
2 x RS-232 COM (RS-422/485)* 3 x USB 2.0 / 2 x USB 3.0 2 x Gigabit Ethernet (RJ-45) 1 x VGA 1 x HDMI |
| Stereo Speaker |
10 W x 2 |
10 W x 2 |
10 W x 2 |
| Bus expansion |
Full-size MiniPCIe/mSATA |
Full-size MiniPCIe/mSATA |
Full-size MiniPCIe / M.2 |
| Dimensions (W x H x D) |
990.6 x 578.8 x 60.2mm (Mirror Glass) 1016.9 x 605.2 x 60.5mm (Pcap / Mirror Pcap*) |
990.6 x 578.8 x 60.2mm (Mirror Glass) 1016.9 x 605.2 x 60.5mm (Pcap / Mirror Pcap*) |
990.6 x 578.8 x 60.2mm (Mirror Glass) 1016.9 x 605.2 x 60.5mm (Pcap / Mirror Pcap*) |
| Weight |
24.6 kg |
24.6 kg |
24.6 kg |
OS Support
|
WES 7P 32bit WES 7E 32bit Windows Pro Embedded 7 SP1 64bit WES 8 64bit Windows Embedded 8.1 Industry Pro 64bit Win 10 IoT Enterprise Linux Ubuntu 16.04 Android 4.4.2 |
WES 7P 32bit WES 7E 32bit Windows Pro Embedded 7 SP1 64bit WES 8 64bit Windows Embedded 8.1 Industry Pro 64bit Win 10 IoT Enterprise Linux Ubuntu 16.04 |
Win 10 IoT Enterprise Android 6.0 Linux Ubuntu 17.04 |
Environmental Specifications
|
|
|
|
| Operating Temperature |
0 ~ 40° C (32 ~ 104° F) |
0 ~ 40° C (32 ~ 104° F) |
0 ~ 40° C (32 ~ 104° F) |
| Relative Humidity |
10 ~ 95% @ 40° C non-condensing |
10 ~ 95% @ 40° C non-condensing |
10 ~ 95% @ 40° C non-condensing |
| Vibration |
0.5G |
0.5G |
0.5G |
| Shock |
5 G peak acceleration (11 msec. duration) |
5 G peak acceleration (11 msec. duration) |
5 G peak acceleration (11 msec. duration) |
| Front Panel Protection |
IP65/ NEMA4 Compliant |
IP65/ NEMA4 Compliant |
IP65/ NEMA4 Compliant |
Power
|
|
|
|
| Input Rating |
100-240VAC ~ 50/60Hz 3.7A |
100-240VAC ~ 50/60Hz 3.7A |
100-240VAC ~ 50/60Hz 3.7A |
LCD Display
|
|
|
|
| Size/Type |
42.5" TFT LCD with LED backlight |
42.5" TFT LCD with LED backlight |
42.5" TFT LCD with LED backlight |
| Max.Resolution |
1920 x 1080 |
1920 x 1080 |
1920 x 1080 |
| Pixel Pitch (mm) |
0.49 (H) x 0.49 (W) |
0.49 (H) x 0.49 (W) |
0.49 (H) x 0.49 (W) |
| Brightness (cd/m2 ) |
450 nits |
450 nits |
450 nits |
| View Angle |
Horizontal: ±89° or 178° total / Vertical: ±89° or 178° tota |
Horizontal: ±89° or 178° total / Vertical: ±89° or 178° tota |
Horizontal: ±89° or 178° total / Vertical: ±89° or 178° tota |
Touch Screen Option (PE/GE)
|
|
|
|
| Type |
Projected Capacitive Touch Panel / Mirror Glass Panel (No touch function) / Mirror Projected Capacitive Touch Panel* |
Projected Capacitive Touch Panel / Mirror Glass Panel (No touch function) / Mirror Projected Capacitive Touch Panel* |
Projected Capacitive Touch Panel / Mirror Glass Panel (No touch function) / Mirror Projected Capacitive Touch Panel* |
| Light Transmission |
>90% (Pure Glass); >25% (Mirror Coating) |
>90% (Pure Glass); >25% (Mirror Coating) |
>90% (Pure Glass); >25% (Mirror Coating) |
| Controller |
USB Interface |
USB Interface |
USB Interface |
