Serial Device Server , 4 x RJ45 RS-232/422/485, 2 x RJ45 Current Loop Advantech BB-ESP906CL

Price and avalability

Partnumber Description Price VAT incl Avalability
BB-ESP906CL Мережевий пристрій/Перетворювач інтерфейсів Advantech, 4 x RJ45 RS-232/422/485, 2 x RJ45 Current Loop  46 148,8

Serial Device Server, 4 x RJ45 RS-232/422/485, 2 x RJ45 Current Loop

B&B Electronics' new Model ESP906CL integrates the benefits of Ethernet communications with existing serial devices by offering four configurable RS-232/422/485 serial ports and two digital current loop ports. The Ethernet connection will auto select 10BaseT or 100BaseTX. The ESP906CL provides a Windows host control over serial devices located virtually anywhere on a TCP/IP or UDP/IP Ethernet connection. It even gives authorized users control over the connected serial device or the ESP906CL Menu from anywhere outside the LAN.

  • Serial Device Server
  • Supports 10/100 Mbps Ethernet
  • Supports RS-232, RS-422, and RS-485 and digital current loop interfaces

Additional information

Part Number BB-ESP906CL


Technology Serial
Serial Port Count 6
Serial Type RS-232/422/485, CL
Ethernet Port Count 1
Mounting Panel
Power 36VDC
Temperature 0 to 40C
