Compact PC UNO-1372G-J

Advantech Control DIN-rail fanless PC with Intel® Atom™ Quad-Core Small Size, 3 x GbE, built-in 4GB DDR3L, 2 x mPCIe, 1 mSATA, 2 x COM, 8 x DI/O, 3 x USB, HDMI, VGA

Industrial Computer >> Embedded computers and fanless BoxPCs

 Price and avalability

Manufacturer: Advantech Co., Ltd.

The UNO-1372G is an Intel Atom Quad-Core DIN-Rail controller. This controller featured with dual power input that shorten the down time to enhance operation excellence. The general purpose input/output ports also help machine builders integrate direct control of start/stop inspection and indicate inspection results. The UNO-1372G is also equipped with Advantech iDoor technology that uses iDoor modules to extend this product to become a gateway controller, such as a PoE card, or isolation serial port card. The UNO-1372G also features 3 gigabyte LAN ports, 1 USB 3.0 port, 2 COM ports and HDMI& VGA display ports for essential upstream and downstream links, for example, PoE connected to IP camera from iDoor.

  • Intel® Atom E3845 1.91GHz processor with 4GB DDR3L Memory
  • 3 x GbE, 3 x USB, 2 x COM, 1 x VGA, 1 x HDMI, Audio, iDoor, mSATA, 2 x mPCIe, 1 x SATA, 4 x DI, 4 x DO, 1 x Power Terminal
  • Compact with Fanless Design
  • Dual Power Input for avoiding Power Down Time
  • Exchangeable RTC Battery with easy Access on the Top
  • Digital I/O with Isolation Protection for Sensing and controlling
  • Diverse system IO and Supports Fieldbus Protocol by iDoor Technology as a Protocol Gateway
  • 3G/GPS/GPRS/Wi-Fi Communication by iDoor Technology as a Communication Gateway
  • Supports MRAM by iDoor Technology
  • LAN Redundancy (Teaming)

Price and avalability

Partnumber Description Price VAT incl Avalability
UNO-1372G-BTO104/W7P Промышленный компактный компьютер UNO-1372G-J1900 2.0GHz, 4G RAM SSD 64Gb (-40~85°C) WS7P x64  29 113,2 Доступно
UNO-1372G-BTO103/W10E Промышленный компактный компьютер UNO-1372G-J1900 2.0GHz, 4G RAM SSD 64Gb (-40~85°C) WIN10ENT 2016LTSB   27 323,7 Доступно
UNO-1372G-J021AE Промисловий компактний комп`ютер на DIN рейку Celeron J1900 2 GHz QC, 4GB DDR, iDoor, DP/HDMI/2LAN/COM/2USB  19 953,3 Доступно
UNO-1372G-E3AE Промышленный компактный компьютер на DIN рейку Atom QC 1.91GHz, 4GB DDR, iDoor, 3LAN, 2COM  27 788,4
PCM-24R2GL-AE Модуль iDoor для UNO-xxxx и PPC-3xxx, 2 Port Giga LAN Intel i350 PCIe mini card  3 491,7
PCM-24D2R2-BE Модуль iDoor для UNO-xxxx и PPC-3xxx, Isolated RS-232, DB9 x 2, (USB type)  3 640,3
PCM-24D4R2-BE Модуль iDoor для UNO-xxxx и PPC-3xxx, Non-Isoted RS-232, DB37 x 1 (USB Type)  3 640,3
PCM-26R2PN-MAE 2PORT, PROFINET, HILSCHER FIELDBUS MPCI  19 131,9
PCM-26D1DB-MAE 2PORT, PROFIBUS, HILSCHER FIELDBUS MPCI  18 840,9
