Thin and light protected tablet R11/ R11L

11.6″ protected tablet R11/ R11L IP65 with MIL STD-461F

Industrial Computer >> Rugged laptops and tablets

 Price and avalability

Manufacturer: DURABOOK (TWINHEAD)

Every inch and detail of the Durabook R11/R11L is designed to maximize the efficiency of professional field workers. The Durabook R11 is only 20mm (0.78″) in height and weighs just 1.2kg (2.7lb), making it the world’s most compact tablet in the fully-rugged class. Adding to its appeal is a smooth, streamlined exterior that complements its tough image.

Key features:

  • Thin, light and streamlined
  • 11.6” FHD (1920×1080) LCD
  • MIL-STD-810G and MIL-STD-461F, ANSI 12.12.01 C1D2 certified
  • 10-point capacitive multi-touch panel can be used with a glove, stylus or finger even in wet weather.

Price and avalability

Partnumber Description Price VAT incl Avalability
R11/FIELD Захищений планшет DURABOOK R11, польова модель, ip65, 11,6" FHD 500 ніт, Intel Core i5-8250U, W10 Professional, 8ГБ ОЗП, 128ГБ SSD, 802.11a /b/g/n/ac, Bluetooth 5.0, USB, порт док-станції, 2Мп/5Мп камери,GPS + 4G LTE  117 443,0
R11L/STANDARD Захищений планшет DURABOOK R11, стандартна модель, ip65, 11,6" FHD, Intel Pentium 4417U, W10 Professional, 4ГБ ОЗП, 64ГБ SSD, 802.11a /b/g/n/ac, Bluetooth 5.0, USB, порт док-станції, 2Мп/5Мп камери  71 787,9
R11L/FIELD Захищений планшет DURABOOK R11, польова модель, ip65, 11,6" FHD 500 ніт, Intel Pentium 4417U, W10 Professional, 4ГБ ОЗП, 64ГБ SSD, 802.11a /b/g/n/ac, Bluetooth 5.0, USB, порт док-станції, 2Мп/5Мп камери, GPS + 4G LTE  95 176,6

Additional information

Model

R11

R11L

Rugged Specs


MIL-STD-810G Certified 4′ drop 26 faces, drop, shock, vibration, altitude, freeze/thaw, high/low temperature, temperature shock, humidity) 4′ drop 26 faces, drop, shock, vibration, altitude, freeze/thaw, high/low temperature, temperature shock, humidity)
Electromagnetic MIL STD-461F MIL STD-461F
Water and Dust Resistant IP65 IP65
Hazardous Environment ANSI C1D2 12.12.01 ANSI C1D2 12.12.01

Tech Specs


Display

11.6″ FHD (1920 x1080)

Optional 500 nits DynaVue® sunlight readable display with capacitive multi-touch screen

11.6″ FHD (1920 x1080)

Optional 500 nits DynaVue® sunlight readable display with capacitive multi-touch screen

Operating System Windows® 10 Pro Windows® 10 Pro
Processors Intel® Core™ i7-8650U vPro™ (8th Gen) 1.9GHz up to 4.2GHz processor, 8MB cache
Intel® Core™ i7-8550U (8th Gen) 1.8GHz up to 4.0GHz processor, 8MB cache
Intel® Core™ i5-8350U vPro™ (8th Gen) 1.7GHz up to 3.6GHz processor, 6MB cache
Intel® Core™ i5-8250U (8th Gen) 1.6GHz up to 3.4GHz processor, 6MB cache
Intel® Pentium® 4417U 2.3GHz processor, 2MB cache
Memory 1 slot 8GB up to 16GB (2400MHz DDR4) 1 slot 4GB (2133MHz DDR4)
Storage 128GB SSD
Optional 256GB/512GB SSD
64GB SSD
Graphics Intel® UHD Graphics 620 Intel® HD Graphics 610
Camera Front: Integrated 2MP Webcam
Rear: 5.0MP auto-focus rear camera with flashlight
Front: Integrated 2MP Webcam
Rear: 5.0MP auto-focus rear camera with flashlight
Audio Integrated microphone
Intel® High Definition Audio Compliant
Integrated speaker x 1
Integrated microphone
Intel® High Definition Audio Compliant
Integrated speaker x 1
Keyboard & Pointing Device 6 buttons (1 user-definable) 6 buttons (1 user-definable)
I/O Ports USB 3.0 (type A) x 2
Audio in/out (combo jack) x 1
microSD card (support microSDXC) x 1
Docking connector (35-pin Pogo) x 1
SIM card slot x 1
DC-In jack x 1
Optional RF antenna pass-through for GPS, WWAN4
USB 3.0 (type A) x 2
Audio in/out (combo jack) x 1
microSD card (support microSDXC) x 1
Docking connector (35-pin Pogo) x 1
SIM card slot x 1
DC-In jack x 1
Optional RF antenna pass-through for GPS, WWAN4
Expansion Slots Optional 1D/2D Barcode Reader
Optional RJ-45 x 1 or Smart Card / CAC Reader or RFID2
Optional 1D/2D Barcode Reader
Optional RJ-45 x 1 or Smart Card / CAC Reader or RFID2
Wireless & Communications Intel® Dual Band Wireless AC 9260 (802.11a/b/g/n/ac)
Bluetooth® V5.0
Optional dedicated GPS module (UBLOX-NEO-M8N)4
Optional 4G LTE multi-carrier mobile broadband4
Optional RF antenna pass-through for GPS, WWAN4
Intel® Dual Band Wireless AC 9260 (802.11a/b/g/n/ac)
Bluetooth® V5.0
Optional dedicated GPS module (UBLOX-NEO-M8N)4
Optional 4G LTE multi-carrier mobile broadband4
Optional RF antenna pass-through for GPS, WWAN4
Security Intel® vPro™ Technology (per CPU options)
TPM 2.0
NIST BIOS compliant
Stealth mode
Kensington Lock
Optional RFID reader1
TPM 2.0
NIST BIOS compliant
Stealth mode
Kensington Lock
Optional RFID reader1
Power AC adapter : 100-240V, 50Hz-60Hz, 65W
Main battery Li-Ion, 11.1V, 3950mAh, 8 hours3
Optional Hi-Cap battery Li-Ion 11.1V, 7800mAh, 16 hours3
AC adapter : 100-240V, 50Hz-60Hz, 65W
Main battery Li-Ion, 11.1V, 3950mAh, 8 hours3
Optional Hi-Cap battery Li-Ion 11.1V, 7800mAh, 16 hours3
Dimension & Weight 299 mm (L) x 192 mm (W) x 20 mm (H)
1.2 kg (with 3950mAH battery)
299 mm (L) x 192 mm (W) x 20 mm (H)
1.2 kg (with 3950mAH battery)
Warranty 3-year limited warranty standard 3-year limited warranty standard

  1. Contact your sales representative for feature availability.

  2. RJ45, Smart Card reader and RFID are mutually exclusive options.

  3. Tested using the MobileMark 2014 battery life benchmark. Results may vary under different situations including hardware configuration, software, operating conditions, power management settings and other factors.

  4. WWAN and GPS are mutually exclusive.

  1. Contact your sales representative for feature availability.

  2. RJ45, Smart Card reader and RFID are mutually exclusive options.

  3. Tested using the MobileMark 2014 battery life benchmark. Results may vary under different situations including hardware configuration, software, operating conditions, power management settings and other factors.

  4. WWAN and GPS are mutually exclusive.
