9th/8th Gen Intel® Xeon®/Core™ Embedded GPU Computer, Supports 1x MXM 3.1 GPU Expansion Socket Cincoze GM-1000

Price and avalability

Partnumber Description Price VAT incl Avalability
GM-1000-R10 Високопродуктивний компактний комп'ютер Cincoze GM-1000-R10, 9th/8th Gen Intel® Xeon®/Core™ Embedded GPU Computer, Supports 1x MXM 3.1 GPU Expansion Socket  74 221,4

The GM-1000 is a rugged GPU computing platform supporting embedded MXM GPU expansion. It has all the features required for a compact, reliable, and high-performance computing system for field applications in machine vision, image processing, and artificial intelligence. Based on the latest Intel® Coffee Lake-R platform, GM-1000 is able to equip with 9th/8th generation workstation grade processor up to 8 cores and dual DDR4-2666 SO-DIMM memory up to 64 GB, that can deliver outstanding computing performance for high-end applications. The compact GPU system, sized at 260 mm x 200 mm x 85 mm, can accommodate 1 x standard MXM 3.1 Type A/B form factor GPU module slot. It allows GPU-accelerated technology from NVIDIA® or AMD® to speed up intensive workloads by executing massive parallel processing, delivering an optimized performance for demanding embedded vision computing applications. The unique thermal design is adopted for GM-1000 to maximize the heat dissipation efficiency and allows GM-1000 to thrive in extreme environmental conditions. The thermal solution is made possible with the design of industrial grade components, copper heat pipes, a special aluminum extrusion case, and an optional external fan. This thermal design provides effective heat dissipation and allows high performance GPU applications with reliability. Moreover, the GM-1000 supports extra functionality and I/O expansions. Thru Cincoze’s innovative CMI / CFM (Combined Multiple IO / Control Function Module) technologies, the GM-1000 can be extended with PoE, power ignition sensing, and various I/Os such as LAN, M12, DIO, USB, and COM. The technologies provide a customized expansion to fulfill each user’s specific needs and applications.

  • Supports 9th/8th Gen Intel® Xeon®/Core™ Processor up to 8 cores
  • Supports 1x MXM 3.1 Type A/B form factor GPU module expansion
  • 2x DDR4 SO-DIMM sockets, up to 2666MHz, 64GB
  • Supports wide operating temperature (-40°C - 70°C) and vibration/shock tolerance (5G/50G)
  • 260 mm x 200 mm x 85 mm compact footprint
  • Flexible functionality expansions: - M.2 E key (CNVi), full-size Mini-PCIe and M.2 M Key (NVMe SSD): - Proprietary CMI interface for various I/O expandability / - Proprietary CFM interface for PoE+ or Power Ignition Sensing

Additional information

Specifications

Processor

9th Generation Intel® Coffee Lake-R CPU
  • Intel® Xeon® E-2278GE 8 Cores Up to 4.7 GHz, TDP 80W
  • Intel® Xeon® E-2278GEL 8 Cores Up to 3.9 GHz, TDP 35W
  • Intel® Core™ i7-9700E 8 Cores Up to 4.4 GHz, TDP 65W
  • Intel® Core™ i5-9500E 6 Cores Up to 4.2 GHz, TDP 65W
  • Intel® Core™ i3-9100E 4 Cores Up to 3.7 GHz, TDP 65W
  • Intel® Core™ i7-9700TE 8 Cores Up to 3.8 GHz, TDP 35W
  • Intel® Core™ i5-9500TE 6 Cores Up to 3.6 GHz, TDP 35W
  • Intel® Core™ i3-9100TE 4 Cores Up to 3.2 GHz, TDP 35W
8th Generation Intel® Coffee Lake CPU
  • Intel® Xeon® E-2176G 6 Cores up to 4.7 GHz, TDP 80W
  • Intel® Xeon® E-2124G 4 Cores up to 4.5 GHz, TDP 71W
  • Intel® Core™ i7-8700 6 Cores up to 4.6 GHz, TDP 65W
  • Intel® Core™ i5-8500 6 Cores, up to 4.1 GHz, TDP 65W
  • Intel® Core™ i3-8100 4 Cores 3.6 GHz, TDP 65W
  • Intel® Core™ i7-8700T 6 Cores up to 4.0 GHz, TDP 35W
  • Intel® Core™ i5-8500T 6 Cores up to 3.5 GHz, TDP 35W
  • Intel® Core™ i3-8100T 4 Cores 3.1 GHz, TDP 35W
  • Intel® Pentium® G5400 2 Cores 3.7 GHz, TDP 58W
  • Intel® Pentium® G5400T 2 Cores 3.1 GHz, TDP 35W
  • Intel® Celeron® G4900 2 Cores 3.1 GHz, TDP 54W
  • Intel® Celeron® G4900T 2 Cores 2.9 GHz, TDP 35W

Chipset

Intel® C246
BIOS AMI BIOS

Memory

  • 2x DDR4-2666/2400 MHz SO-DIMM Sockets
  • Support up to 64 GB (Un-buffered and non-ECC type)

* Xeon/i7/i5: Up to DDR4 2666MHz

* i3/Pentium/Celeron: Up to DDR4 2400MHz

Graphics

  • Integrated Intel® UHD Graphics (Xeon/i7/i5/i3: UHD 630; Pentium/Celeron: UHD 610)
  • Supports Triple Independent Display (DVI-I/DisplayPort/HDMI)

Audio Codec

Realtek® ALC888, High Definition Audio

I/O Interface

  • 1x DVI-I Connector (VGA: 1920 x1080 @ 60 Hz; DVI-D: 1920 x1200 @ 60 Hz)
  • 1x DisplayPort Connector (4096 x 2304 @ 60Hz)
  • 1x HDMI Connector (4096 x 2160 @ 30Hz)
  • 2x GbE LAN Ports (Supports WoL, Teaming, Jumbo Frame & PXE), RJ45 ( - GbE1: Intel® I219-LM / - GbE2: Intel® I210-IT)
  • 4x RS-232/422/485 Ports with Auto Flow Control (Support 5V/12V), DB9
  • 4x 10Gbps USB3.2 Gen2 Ports, Type-A
  • 4x 5Gbps USB3.2 Gen1 Ports, Type-A
  • 1x Line-out & 1x Mic-in, Phone Jack 3.5mm
  • 1x ATX Power On/Off Button
  • 1x Reset Button
  • 1x AT/ATX Mode Switch
  • 1x Clear CMOS Switch
  • 1x Remote Power On/Off Connector, 2-pin Terminal Block
  • 2x External Fan Connectors, 4-pin Terminal Block (Supports Smart Fan by BIOS)

Storage

  • 2x SATA III (6Gbps) Front Accessible 2.5” HDD/SSD Trays (up to 15mm in Height)
  • 3x mSATA Sockets (Shared by Mini-PCIe Socket)
  • Supports S/W RAID 0, 1, 5 & 10 • 1x PCIe x4 M.2 Key M 2280 Socket, Supports NVMe SSD

Expansion

CMI (Combine Multiple I/O ) Interface

1x High Speed CMI Interface for I/O Expansion

  • CMI-10GLAN01 : 2x 10G Intel® X550 RJ45 LAN
  • CMI-LAN01 : 4x 1G Intel® I210-IT RJ45 LAN
  • CMI-M12LAN01 : 4x 1G Intel® I210-IT M12 LAN

1x Low Speed CMI Interface

  • CMI-COM01 : 2x RS232/422/485, Support 5V/12V
  • CMI-DIO01 : 16x DIO (8 in, 8 out)

1x CFM IGN Interface - CFM-IGN01: Ignition Sensing Function

1x MXM Carrier Board Interface for MXM GPU Module Expansion

1 x PCIe x2 M.2 Key E 2230 socket, support Intel CNVi Module

3x Full-size Mini-PCIe Sockets

2x SIM Sockets

2x Antenna Holes

Other Function

  • Instant Reboot: Support 0.2 sec. Instant Reboot Technology
  • SuperCap Integrated for CMOS Battery Maintenance-free Operation
  • Watchdog Timer: Software Programmable Supports 256 Levels System Reset

Power Requirement

  • Supports AT/ATX Power Type
  • Total Power Budget: 360W
  • Power Input Voltage: 9-48 VDC, Single Power Source
  • Connector Type: 2x 3-pin Terminal Block, Each Terminal Block Current Limitation is 15A
  • Power input voltage from 9V to 23V must use dual power connectors, power input voltage from 24V to 48V can use single power connector
  • Power Adaptor (- Optional AC/DC 24V Power Adapter, 220W)
