Embedded PC MIC-730AI

AI Inference System Advantech MIC-730AI based on NVIDIA Jetson® Xavier

Industrial Computer >> Embedded computers with expansion slots

 Price and avalability

Manufacturer: Advantech Co., Ltd.

AI Inference System based on NVIDIA Jetson® Xavier

  • NVIDIA Jetson™ Xavier embedded
  • Fanless compact design
  • Support 1 x MiniPCIe & 1 x M.2 (PCIex4 NVMe)
  • Bundles with Linux Ubuntu 18.04
  • Low power consumption
  • Support PCIe Add-on Card
  • Support 24/7 secure remote monitoring, control, and OTA deployment empowered by Allxon (support JetPack 4.4GA and above)

MIC-730AI-00A1 Memory: LPDDR4 16G 1333MHz

MIC-730AI-10A1 Memory: LPDDR4 32G 1333MHz

Price and avalability

Partnumber Description Price VAT incl Avalability
MIC-730AI-00A1 NVIDIA Jetson AGX Xavier AI Inference System  118 187,0
MIC-730AI-10A1 Система штучного інтелекту Advantech на базі NVIDIA Jetson AGX Xavier_32G AI Inference System  128 433,0

Additional information

Processor System



Flash

16G of eMMC

CPU

ARM v8.2 64-bit CPU

GPU

512 NVIDIA CUDA cores 64 Tensor cores

Deep Learning Accelerator

5 TFLOPS (FP16) 10 TOPS (INT8)

Memory

16/32 GB 256-bit LPDDR4

Storage

32GB eMMC 5.1

Ethernet



Interface

2 x RJ-45

Controller

Intel® i210IT

Speed

10/100/1000 Mbps

I/O



USB

2 x USB3.0 + 3x USB 2.0

Power Switch

Power ON/OFF Switch x 1

Display

HDMI (Max. resolution 3840x2160 @ 60Hz)

Digital I/O

16 bit

OTG USB

MicroUSB x 1

COM

2 x RS-232/RS-422/RS-485

Expansion Interface



Mini PCIe

1

PCI Express x 8

1

Power



Power Type

ATX/AT

Supply Voltage

9-36V

Environment



Operating Temperature

-10 ~ 60° C (14 ~ 144° F)

Operating Humidity

95% @ 40 °C, non-condensing

Vibration

0.5 Grms @ 5 ~ 500 Hz, random, 1 hr/axis

Mechanical

Install

Desktop/Wall-mounting

Dimension

192 x 230 x 87 mm

Weight

4.5 kg

OS



Linux

Ubuntu 18.04

Certification



Safety Certifications


CE/FCC/BSMI

Storage



HDD

1 x 2.5” SSD/HDD Easy-Swap bay
